Venture iE

Assembly Options Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Hydraulic disc
Tire Size
Frame material

Recharge and reconnect with simple pleasures on the Venture iE. Built on a lightweight aluminum frame, this electric bike features a low step-through for easy on and off. The smooth-shifting Shimano 9-speed drivetrain lets you find your natural cadence while the industry-leading Bosch Active Line Plus motor works with your natural pedaling to provide gentle acceleration up to 20mph. The Purion Display allows you to track your speed and distance while easily adjusting the level of assistance needed. An adjustable stem lets you customize the angle of the handlebars for optimal comfort. The 27.5-inch wheels are easy to maneuver and wide Schwalbe tires add traction and control. Regain a sense of freedom and renewed energy on the Venture iE.

  • Bike Frame Fully Formed Lightweight Aluminum Alloy 6061 T6, Nested ST Battery
  • Bike Rear Shock *
  • Bike Fork Aluminum Alloy Oversize Blades, Disc Brake Mounts
  • Bike Headset Integrated, Sealed Mechanism
  • Bike Cranks FSA Cast Alloy, 170mm
  • Bike Sprocket FSA 42 Tooth w/Chainguard
  • Bike Bottom Bracket *
  • Bike Front Derailleur *
  • Bike Rear Derailleur Shimano Alivio SGS, 9 Speed
  • Bike Shifter Shimano Alivo, Rapidfire Plus, 9 Speed
  • Bike Cogset Shimano HG400, 12-36 Tooth, 9 Speed
  • Bike Chain KMC x9ePT Ebike Specific
  • Bike Front Hub Formula, Alloy, w/QR 36 Hole
  • Bike Rear Hub Formula, Alloy, w/QR 36 Hole
  • Bike Spokes Black w/Silver Nipples
  • Bike Rims Alloy Double Wall, 36 Hole
  • Bike Tires Schwalbe Supermoto-X 27.5x2.40
  • Bike Brake Levers Tektro Hydraulic Ergo 4 Finger
  • Bike Pedals Urban Style, Steel Cage w/Resin Body
  • Bike Handlebar Raleigh Aluminum Alloy
  • Bike Grips Raleigh Ergo Comfort Control
  • Bike Stem Alloy Adjustable Height, Comfort Stem
  • Bike Seat Raleigh Custom Ergo Comfort
  • Bike Seatpost Raleigh Aluminum Alloy, Forged Head
  • Bike Detangler *
  • Bike Extras Adjustable Kickstand
  • Bike Tape *
  • Bike Battery Bosch Powertube 400Wh, DT Mount
  • Bike Charger Bosch Compact Charger 2 Amp
  • Bike Motor Bosch Active Line Plus, 50Nm Torque, 20 mph, Made in EU
  • Bike Display Bosch Purion, Performance Line
  • Bike Range Estimated 20mi (34km) - 53mi (85km)
  • Bike Accessories Bosch Compact Charger 2A
  • Bike Brakes Tektro Hydraulic Disc 160mm
  • Product ID 4575
Frame Size SM 5'3" - 5'5" MD 5'6" - 5'9" LG 5'10" - 6'1"
Rider Height - - -
Bike Stand Over Height 410.0 mm 410.0 mm 410.0 mm
Bike Seat Tube Length 410.0 mm 460.0 mm 510.0 mm
Bike Top Tube Length 600.0 mm 614.0 mm 630.0 mm
Bike Head Tube Length 160.0 mm 180.0 mm 200.0 mm
Bike Head Angle 70.0 mm 70.0 mm 70.0 mm
Bike Seat Angle 73.0 mm 73.0 mm 73.0 mm
Bike Wheel Base 1137.0 mm 1152.0 mm 1169.0 mm
Bike Chain Stay Length 480.0 mm 480.0 mm 480.0 mm
Bike Bb Drop 60.0 mm 60.0 mm 60.0 mm
Bike Stem Length 90.0 mm 90.0 mm
Bike Crank Length 170.0 mm 170.0 mm 170.0 mm
Bike Seat Post Length 350.0 mm 350.0 mm 400.0 mm
Bike Stack 638.0 mm 656.0 mm 675.0 mm
Bike Reach 405.0 mm 413.0 mm 423.0 mm
Add Your Review
How Do You Rate This Product?

There are so many factors that determine your eBike’s range: the size of your battery, the level of motor assist you select, and how much weight you are carrying. Going uphill uses more battery than a flat trail.

To help you figure out the most accurate range estimate for your eBike, please try using Bosch’s range finder tool.
