Misceo iE
$1,800.00
Assembly Options
Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available
Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns
Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty
Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Hydraulic disc
Tire Size
700x45c
Frame material
Aluminum
Sure you can drive, but why, when you can fly on the Misceo iE. Offering an upright riding position and speedy 700c wheels, this commute-ready e-bike lets you feel the wind in your hair. An SR Suntour rear hub motor and downtube-mounted battery pack provide balance and power, with each pedal stroke accelerating up to 20mph. The Shimano 8-speed drive train lets you find your natural cadence, while the SR Suntour suspension fork eats up bumps in the asphalt for a smooth ride. The lightweight hydroformed frame offers internal cable routing for a clean, sleek look and the rear rack, fenders, LED lights, bell, and kickstand make commuting that much easier. Available in step over and step through styles.
- Bike Frame Lightweight Hyrdoformed 7005 Alloy, Internal Cable Routing
- Bike Rear Shock *
- Bike Fork SR Suntour NVS-DS Suspension Fork, 75mm Travel
- Bike Headset Semi-Integrated, Sealed Mechanism
- Bike Cranks SR Suntour Alloy Black, 170mm, with Torque, Cadence and Speed Sensor
- Bike Sprocket 42 Tooth w/Double Chainguard
- Bike Front Derailleur *
- Bike Rear Derailleur Shimano Altus RD-M310, 8 Speed
- Bike Shifter Shimano Altus SL-M315, 8 Speed
- Bike Cogset Shimano HG-31, 11-34 Tooth, 8 Speed
- Bike Chain KMC X8
- Bike Front Hub Formula, 36 Hole, W/QR
- Bike Rear Hub SR Suntour E25 Performance Rear Hub, 36 Hole, Bolt-on
- Bike Spokes Black w/Silver Nipples
- Bike Rims 700c Alloy Double Wall, Anodized Black, 36 Hole
- Bike Tires Kenda K-1172, Blackwall, 700x45c
- Bike Brake Levers Tektro 2 Finger Lever
- Bike Pedals Resin Body Urban, Black
- Bike Handlebar Raleigh Alloy Bars, 15mm Rise, 9 Degree Bend
- Bike Grips Raleigh Comfort Control
- Bike Stem Raleigh Aluminum Alloy, 7 Degree Rise
- Bike Seat Raleigh Custom Ergo Performance
- Bike Seatpost Raleigh Aluminum Alloy, Forged Head, 350mm
- Bike Detangler *
- Bike Extras Alloy Rear Rack, Black Fenders, LED Lights Front & Rear, Alloy Bell, Adjustable Kickstand
- Bike Tape *
- Bike Battery SR Suntour Li-Ion 410Wh Downtube Mounted, w/Lockset
- Bike Charger SR Suntour 2 Amp, 36 Volt
- Bike Motor SR Suntour E25 Performance Rear Hub Brushless DC Motor, 250W (400W max), 60Nm Torque
- Bike Display SR Suntour Multi-Function LED Display
- Bike Max Assisted Speed 20 mph (32 kph)
- Bike Range Estimated 15mi (24km) to 62mi (100km)
- Bike Accessories Alloy Rear Rack, Steel Fenders, LED Lights Front & Rear, Alloy Bell, Adjustable Kickstand
- Bike Brakes Tektro Hydraulic Disc, 180mm Rotors
- Product ID 4383
| Frame Size | SM Fits 5'3" - 5'6" | MD Fits 5'6 - 5'9" |
|---|---|---|
| Rider Height | - | - |
| Bike Stand Over Height | 650.0 mm | 650.0 mm |
| Bike Seat Tube Length | 400.0 mm | 450.0 mm |
| Bike Top Tube Length | 580.0 mm | 595.0 mm |
| Bike Head Tube Length | 145.0 mm | 170.0 mm |
| Bike Head Angle | 69.0 mm | 69.0 mm |
| Bike Seat Angle | 73.0 mm | 73.0 mm |
| Bike Wheel Base | 1133.0 mm | 1149.0 mm |
| Bike Chain Stay Length | 490.0 mm | 490.0 mm |
| Bike Bb Drop | 70.0 mm | 70.0 mm |
| Bike Stem Length | 90.0 mm | 100.0 mm |
| Bike Handlebar Width | 620.0 mm | 620.0 mm |
| Bike Crank Length | 170.0 mm | 170.0 mm |
| Bike Seat Post Length | 350.0 mm | 350.0 mm |
| Bike Stack | 634.0 mm | 657.0 mm |
| Bike Reach | 386.0 mm | 394.0 mm |
| Bike Fork Travel | 63.0 mm | 63.0 mm |
